SFP Connector, SFP+ Connector, Replacement for UE75A206000T Amphenol Commercial Products, ESFP13031401C (Free Sample)

BACK
CONTACT US TODAY

FEATURES

AICO Intr Number : ESFP13031401C

Form Factor : SFP

Product Type : Connector  Receptacle

Connector System: Cable-to-Board

Number of Positions: 20

Termination: Solder

Mounting Type: Surface Mount, Right Angle

Terminal Material: Copper Alloy

Housing Material: LCP UL 94V-0  Color: Black

Plating: 1. 1.27um Min. Ni underplating  2. 0.76um Min. Matte tin Plating ON SMT  3. 0.38um OR 0.76um Min. Gold Plating on contact area

For Use With : SFP Cage / SFP+ Cage

Connector Height :  5.30mm

Connector Width  : 11.00mm

Operation Temperature: -40℃~+85℃

Storage Temperature: -55℃~+105℃

Packaging Method : Tape

The circuits are only for reference, we could design different circuit for different mechanical structure according to customer requirement.



Product Drawing (PDF Download Available):

SFP Connector, SFP+ Connector, SFP Plus Receptacle, Replacement for UE75A206000T Amphenol Commercial Products, ESFP13031401C

Download Link : https://www.aico-electronics.com/wp-content/uploads/2016/06/AICO-SFP-Plus-Connector-Receptacle-drawing-ESFP13031401C.pdf
